DTX6 Series
Product Information
DTX6K-X
- Faithfully reproduces real drum kit sounds and ambience recorded in world renowned studios
- AMBIENCE, COMP, and EFFECT Kit Modifier knobs that allow you to create your own unique sounds
- Yamaha's original TCS head is used on the snare pad to achieve a realistic, natural feel and rebound that makes you want to keep playing
- 3-zone pads for the snare, and ride. The cymbals can be choked and muted. Ride cymbal equipped with a hit point detection function (positional sensing)
- Yamaha's traditional ball clamp is used for the snare clamp
DTX6K-X SPECIFICATIONS
| Module | DTX-PRO | |
|---|---|---|
| Pad | Snare | XP80 (8 inch) TCS head 3-zone pad |
| Tom 1, 2 | TP70 (7 inch) Rubber head 1-zone pad | |
| Floor Tom | TP70 (7 inch) Rubber head 1-zone pad | |
| Bass Drum | KP65 (5 inch) rubber pad double foot pedal compatible | |
| Hi-Hat | 10 inch pad and HH65 Hi-Hat controller | |
| Crash Cymbal 1 | 10 inch pad with Choke ability | |
| Crash Cymbal 2 | - | |
| Ride Cymbal | PCY135 (13 inch) 3-zone pad | |
| Hi-Hat Stand | - | |
| Rack System | DTX6K-X Rack | |
DTX6K2-X
- Faithfully reproduces real drum kit sounds and ambience recorded in world renowned studios
- AMBIENCE, COMP, and EFFECT Kit Modifier knobs that allow you to create your own unique sounds
- Yamaha's original TCS head is used on the snare pad to achieve a realistic, natural feel and rebound that makes you want to keep playing
- 3-zone pads for the snare, crash, and ride. The cymbals can be choked and muted. The ride cymbal is equipped with a hit point detection function (positional sensing)
- Yamaha system hardware is used for the included hi-hat stand and snare arm.
DTX6K2-X SPECIFICATIONS
| Module | DTX-PRO | |
|---|---|---|
| Pad | Snare | XP80 (8 inch) TCS head 3-zone pad |
| Tom 1, 2 | TP70 (7 inch) Rubber head 1-zone pad | |
| Floor Tom | TP70 (7 inch) Rubber head 1-zone pad | |
| Bass Drum | KP90 (7.5 inch) rubber head with Multi layer cushion | |
| Hi-Hat | RHH135 (13 inch) 2-zone pad | |
| Crash Cymbal 1 | PCY135 (13 inch) 3-zone pad | |
| Crash Cymbal 2 | PCY135 (13 inch) 3-zone pad | |
| Ride Cymbal | PCY135 (13 inch) 3-zone pad | |
| Hi-Hat Stand | HS650A | |
| Rack System | RS6 | |
DTX6K3-X
- Faithfully reproduces real drum kit sounds and ambience recorded in world renowned studios
- AMBIENCE, COMP, and EFFECT Kit Modifier knobs that allow you to create your own unique sounds
- Yamaha's original TCS head is used for all pads achieving a realistic, natural feel and rebound that makes you want to keep playing
- 3-zone pads for the snare, crash, and ride. The cymbals can be choked and muted. The ride cymbal is equipped with a hit point detection function (positional sensing)
- Yamaha system hardware is used for the included hi-hat stand and snare arm.
DTX6K3-X SPECIFICATIONS
| Module | DTX-PRO | |
|---|---|---|
| Pad | Snare | XP80 (8 inch) TCS head 3-zone pad |
| Tom 1, 2 | XP70 (7 inch) TCS head 1-zone pad | |
| Floor Tom | XP70 (7 inch) TCS head 1-zone pad | |
| Bass Drum | KP90 (7.5 inch) rubber head with Multi layer cushion | |
| Hi-Hat | RHH135 (13 inch) 2-zone pad | |
| Crash Cymbal 1 | PCY135 (13 inch) 3-zone pad | |
| Crash Cymbal 2 | PCY135 (13 inch) 3-zone pad | |
| Ride Cymbal | PCY135 (13 inch) 3-zone pad | |
| Hi-Hat Stand | HS650A | |
| Rack System | RS6 | |
